VACUUM TUBE SOCKETS
|
Made in USA These US made new old stock Elco Micalex seven pin tube sockets are bottom mounting in a 19/32" chassis hole on 7/8" centers for seven pin miniature (B7G) base tubes such as the 6AQ5, 6AV6, 6C4, 50C5 etc. Elco EIA code 599.
$2.70 |
|
Made in USA These US made new old stock bottom mounting seven pin tube sockets are bottom mounting in a 5/8" chassis hole on 7/8" centers for seven pin miniature (B7G) base tubes such as the 6AQ5, 6AV6, 6C4, 50C5 etc.
SORRY - Sold Out - or -
Special Price for 10 sockets
|
|
Made in USA 1 ONLY AVAILABLE These US made new old stock Cinch shielded base seven pin ceramic tube sockets are marked with military part number TS102C01 and are top mounting sockets mounting in a 5/8" chassis hole on 7/8" centers for seven pin miniature (B7G) base tubes such as the 6AU6, 6BA6, 6C4, 7693 etc. These Cinch ceramic B7G tube sockets have shield base attached to the socket for standard bayonet type (J slot, push & turn) tube shield if required (shield not included).
$4.50 |
|
Made in USA These new old stock US made Cinch shielded base seven pin micalex (mica filled Phenolic) tube sockets are top mounting sockets mounting in a 5/8" chassis hole on 7/8" centers for seven pin miniature (B7G) base tubes such as the 6AU6, 6BA6, 6C4, 7693 etc. These Cinch B7G tube sockets have shield base attached to the socket for standard bayonet type (J slot, push & turn) tube shield if required (shield not included).
$3.50 - or - Special Price for 10 sockets |
|
Made in USA These US made new old stock Cinch shielded base seven pin miniature tube sockets are top mounting sockets mounting in a 5/8" chassis hole on 7/8" centers for seven pin miniature (B7G) base tubes such as the 6AU6, 6BA6, 6C4, 7693 etc. These Cinch B7G tube sockets have shield base attached to the socket for standard bayonet type (J slot, push & turn) tube shield if required (shield not included).
$3.00 |
|
Made in Japan These new old stock seven pin miniature shielded base tube sockets are top mounting sockets mounting in a 5/8" chassis hole on 7/8" centers for seven pin miniature (B7G) base tubes such as the 6AU6, 6BA6, 6C4, 7693 etc. These Cinch B7G tube sockets have shield base attached to the socket for standard bayonet type (J slot, push & turn) tube shield if required (shield not included). 8 ONLY AVAILABLE
$3.50 |
|
Made in China
These new production ceramic top mounting Printed Circuit Board (PCB) sockets are for seven pin miniature (B7G) base tubes such as the 6AQ5, 6AV6, 6C4, 50C5 etc.
2 for $3.00 |
|
Made in USA Plexicon sockets are the most effective method of by-passing tube pins with condenser close to tube element for the shortest path to ground. These Plexicon sockets are by-passed with internal 1000 MMFD capacitors to ground on pins 3, 6 and 7. These new old stock US made Cinch-Erie "Plexicon" tube sockets are bottom mounting sockets mounting in a 5/8" chassis hole on 7/8" centers for seven pin miniature (B7G) base tubes requiring RF by-passing on pins 3, 6 and 7. 4 ONLY AVAILABLE
$5.00 |
|
Made in USA These new old stock US made Elco special 7 pin Printed Circuit Board (PCB) tube sockets are top mounting sockets mounting with 3/16" spacing between socket mounting pins plus four (1" X 3/8") frame mounting pins for seven pin miniature (B7G) base tube sockets. 8 ONLY AVAILABLE
$7.50 |
|
Made in USA SORRY - Sold Out These new old stock US made Cinch Jones 2H7 7 pin in-line tube sockets are top mounting sockets mounting in about a 1/8" X 7/16" rectangular slot for 2H7 base tubes like the 1V6, 2G21, 2G22, 5829 etc. These tube sockets are used exstensively for hearing aids, radio and other tube electronic apparatus. Molded from mica filed low loose Bakelite with silver plated beryllium copper contacts.
SOLD OUT |
|
(top mount with no center post) Made in China These are new production top mounting sockets mounting in a 3/4" chassis hole on 1 1/8" centers for shielded nine pin miniature (B9A/Noval) base tubes such as the 12AX7, 12AU7, 6267 (EF86), 6922, 7308 etc. These new production B9A tube sockets have shield base attached to the socket for standard bayonet type (J slot, push & turn) tube shield if required (shield not included).
$1.80 - or - Special Price for 10 sockets |
|
Made in USA Sorry SOLD OUT These are new old stock top mounting sockets mounting in a 3/4" chassis hole on 1 1/8" centers for nine pin miniature (B9A/Noval) base tubes such as the 12AX7, 12AU7, 6BQ5/EL84, 6CW5/EL86 etc.
SOLD OUT |
|
New old stock 9 pin miniature (B9A) phenolic wafer tube socket Made in USA These are new old stock bottom mounting sockets mounting in a 3/4" chassis hole on 1 1/8" centers for nine pin miniature (B9A/Noval) base tubes such as the 12AX7, 6EU7, 6267, 7199 etc These are inventory clearance of NOS B9A sockets with a residue on the surface (will wash off with alcohol)
$1.00 |
|
Made in USA
These new old stock Cinch nine pin miniature micalex tube sockets are top mounting sockets mounting in a 3/4" chassis hole on 1 1/8" centers for nine pin miniature
(B9A/Noval) base tubes such as the 12AX7, 12AU7, 7025, 6267 etc. 2 ONLY AVAILABLE
$5.50 |
|
Made in USA These new old stock Methode recessed bottom mounting sockets mount in a 7/8" chassis hole on 1 1/8" centers for nine pin miniature (B9A/Noval) base tubes such as the 12AX7, 12AU7, 6BQ5/EL84, 6CW5/EL86 etc. Sorry SOLD OUT
SOLD OUT |
|
Made in China These new production ceramic top mounting Printed Circuit Board (PCB) B9A tube sockets are designed for 11/16" pin circle diameter PCB hole spacing.
2 for $3.00 |
|
Made in China These are bottom mounting sockets mounting in a 3/4" chassis hole on 1 1/8" centers for ten pin miniature Decal (B10A, B10B) base tubes such as the 6AB9, 6AF9, 6U9/ECF201, 6V9/ECH200, 6X9/ECF200, 6Y9/EFL200, ECC2000 etc.
$4.50 |
NUVISTOR TUBE SOCKETS
|
Made in USA Sorry SOLD OUT These new old stock Cinch top mounting sockets require a special 1/2" chassis hole for tab bend (crimp) socket mounting for five pin nuvistor tubes such as the 2CW4, 2DS4, 6CW4, 6DS4, 13CW4, 7586, 7895, 8393 etc.
SOLD OUT |
|
Made in USA (Sorry SOLD OUT) These are bottom mounting sockets mounting in a 1 1/8" chassis hole on 1 1/2" centers for eight pin octal (K8A) base tubes.
SOLD OUT |
|
Made in China These are top mounting sockets mounting in a 1 1/8" chassis hole from 22 gauge (.031") to 18 gauge (.050") chassis thickness for eight pin octal base tubes or cables and can be used with Amphenol 3-13 and 3-24 caps. These octal sockets (K8A) come with retaining ring (wavy washer).
$2.00 |
|
Made in China
These are top mounting sockets mounting in a 1" chassis hole on 1 1/2" centers for eight pin octal (K8A) base tubes such as the 6V6GT, 6L6, 6L6GC, 5U4GB, 5Y3GT,
6CA7/EL34 etc.
$3.00 |
|
Made in USA These are top or bottom mounting sockets mounting in a 1 1/16" chassis hole on 1 5/8" centers for eight pin octal (K8A) base tubes such as the 6V6GT, 6L6, 6L6GC, 5U4GB, 5Y3GT, 6CA7/EL34 etc. ********
$5.00 |
|
Made in USA These are bottom mounting sockets mounting in a 1" chassis hole on 1 5/16" centers for eight pin octal (K8A) base Klystron tubes such as the 2K25, 2K45, KS9-20B, QKK531 etc. 1 ONLY AVAILABLE
$8.00 |
|
Made in UK These Clix wafer style phenolic sockets are bottom mounting sockets mounting in a 1" to 1 1/8" chassis hole on 1 1/2" centers for eight pin loctal (B8B) base tubes such as the 7B4, 7C5, 7F8, 7N7, 7Y4, 14F8, 14N7, 35Y4, 35A5 etc.
$3.50
Special Price for 10 sockets |
|
Made in China These are bottom mounting sockets mounting in a 1" chassis hole on 1 1/2" centers for eight pin loctal (B8B) base tubes such as the 7B4, 7C5, 7F8, 7N7, 7Y4, 14F8, 14N7, 35Y4, 35A5 etc.
$3.50 |
4, 5, 6, 7 PIN GLASS TUBE SOCKETS
|
Made in USA These are chassis bottom mounting sockets mounting in a 1 1/8" chassis hole on 1 1/2" centers for small four pin (UX4/B4G) base tubes such as the 2A3, 300B, 45, 50, 5Z3, 80, 83 etc. Sorry SOLD OUT
SOLD OUT |
|
Made in USA These are chassis bottom mounting sockets mounting in a 1 1/8" chassis hole on 1 1/2" centers for small four pin (UX4/B4G) base tubes such as the 2A3, 300B, 45, 50, 5Z3, 80, 83 etc. Sorry SOLD OUT
SOLD OUT |
|
Made in China These are chassis bottom mounting sockets mounting in a 1 1/4" chassis hole on 1 1/2" centers for small four pin (UX4/B4G) base tubes such as the 2A3, 300B, 45, 50, 5Z3, 80, 83 etc.
$4.50 |
|
Made in China These are chassis bottom mounting sockets mounting in a 1 1/4" chassis hole on 1 1/2" centers for small five pin (UX5) base tubes such as the 27, 47, 56, 76 etc
$5.00 |
|
Made in China These are chassis bottom mounting sockets mounting in a 1 1/4" chassis hole on 1 1/2" centers for small six pin (UX6) base tubes such as the 6B5, 6C6, 6D6, 19, 41, 42, 310A etc
$5.00 |
|
Made in USA These are bottom mounting sockets mounting in a 1 1/8" chassis hole on 1 1/2" centers for small 7 pin (SM7, E small) base tubes such as the 2A7, 2B7, 6A7, 6B7, 6C7, 6D7, 6F7 etc. Sorry SOLD OUT
SOLD OUT |
|
Made in USA Sorry SOLD OUT These are bottom mounting sockets mounting in a 1 1/8" chassis hole on 1 1/2" centers for small 7 pin (SM7, E small) base tubes such as the 2A7, 2B7, 6A7, 6B7, 6C7, 6D7, 6F7 etc.
SOLD OUT |
|
Made in China These are top mounting sockets mounting in a 1 1/16" chassis hole on 1 1/2" centers for nine pin magnoval (B9D/neonoval) base tubes such as the EL509, EL519, PL509, PL519, 6KG6, 40KG6, EL500, EL504, LL500, PL500, 6GB5, 18GB5, 27GB5 etc. PLEASE NOTE; These are 9 pin magnoval base sockets and are not the same as 9 pin compactron (novar) base sockets - please email tube type if in doubt. Sorry SOLD OUT
SOLD OUT |
|
Made in China
These new production top mounting printed circuit board (PCB) sockets are for nine pin magnoval (B9D/neonoval) base tubes such as the EL509, EL519, PL509, PL519, 6KG6,
40KG6, EL500, EL504, LL500, PL500, 6GB5, 18GB5, 27GB5 etc. PLEASE NOTE; These are 9 pin magnoval base sockets and are not the same as 9 pin compactron (novar) base sockets - please email tube type if in doubt.
$4.50 |
12 PIN COMPACTRON TUBE SOCKETS
|
Made in China These new production ceramic tube sockets can be top mounted in a 1 1/16" chassis hole on 1 1/2" centers or bottom mounted in a 1 1/4" chassis hole on 1 1/2" centers for duodecar 12 pin (B12C) base compactron tubes such as the 6AS11, 6C10, 6D10, 6GE5, 6HF5, 6JM6, 6JN6, 6JS6, 6K11, 6KD6, 6LB6, 6LF6, 6Q11, 6U10 etc.
$4.50 |
|
Made in China These new production Stahl 10 valve/tube sockets are top mounting sockets mounting in a 1 1/2" chassis hole on 1 13/16" centers for Stahl 10 and 8* (G10A/Y10A, G8A/Y8A) base valves such as the AZ11, AZ12, AZ31, EF11, EF13, EL11, EL12, EL13, EL156, UEL51 etc. *Stahl 8 (G8A) base tubes can also be used in Stahl 10 sockets (pin 6 & 10 not used)
$4.20 |
|
Made in China These are bottom mounting sockets mounting in a 1 3/16" chassis hole on 1 9/16" centers for nine pin loctal (B9G/T9A) base tubes such as the EC52, EE50, EF50, EFF50, KT67, TT12 etc.
$4.50 |
|
Made in China These new production P valve/tube sockets are bottom* mounting sockets mounting in a 1 5/8" chassis hole on 1 15/16" centers for P base valves such as the AD1, AZ1, AZ4, AL4, AL5, EF9, EL4, EL5, EL6 etc. *can also be top mounted
$3.20 |
|
Made in China These new production British 7 pin (B7/M) valve/tube sockets are top or bottom mounting sockets mounting in a 1 5/8" chassis hole on 1 13/16" centers for B7/M base valves such as the 7A2. 7A3, 8A1, 11A2, A23A, A36C, A70D, ARP3, ARP25, ARP33, DDT, DDT4, KT41, MHD4, NR59, PT4, SP2, SP4, SPT4, TDD4, TH4A, TH4B, VR49 etc.
$4.00 |
|
Made in China These new production 5 pin European valve/tube sockets are top or bottom mounting sockets mounting in a 1 1/8" chassis hole on 1 3/8" centers for 4 or 5 pin* European (A, A4A, B4/O, O5A, B5) base valves such as the DA30, HL2, KT2, KT21, KT24, L2, ML4, ML6, MU12/14, MU2, P2, PA1, PA20, PA40, PM2, PX4, PX25, RE134, RE144, REN804, U10, U12/14, U16, U17, U18, U20, U21, UU4, UU5 etc. *European 4 pin (A, A4A, B4) base valves can be used in these 5 pin (O, O5A, B5) valve sockets (center pin not used)
$4.00 |
|
Made in China These new production 14 pin Diheptal tube sockets are used for many types of cathode ray tubes (CRT), photo multiplier tubes (PMT), image orthicon and Nixie tubes. The 14 pin Diheptal socket can also be used for 12 pin Diheptal base tubes (pins 6 & 13 not used).
$10.90 |
|
Made in China These new production ceramic 12 pin Duodecal tube sockets are used for many types of cathode ray tubes (CRT) such as the 2BP1, 3ADP1, 3AQP1, 3MP1, 3RP1, 3SP1, 3UP1, 3WP1, 4MP1, 5DEP1, 5UP1 and photo multiplier tubes (PMT) such as the 2067, 4440 and 6199.
$6.95 |
|
Made in USA 1 ONLY AVAILABLE
These are bottom mounting sockets mounting in a 1 1/8" chassis hole on 1 1/2" centers for twelve pin sub-magnal base tubes.
$10.00 |
|
Made in USA These are bottom mounting sockets mounting in a 1 1/8" chassis hole on 1 1/2" centers for eleven pin sub-magnal base tubes such as the 1P21, 1P22, 1P28 and 931A Photo Multiplier Tubes.
Heathkit used the 11 pin sub-magnal socket in the HP-23 power supplies and others. Hammond also used 11 pin sub-magnal sockets for Leslie hook up for Hammond keyboards
such as the XB-2 and others and organs such as the 333000, 340000 series and many more.
$10.00 |
|
